RATINGS/ APPROVALS
CONSTRUCTION
Conductors
22AWG-8AWG
Stranded Nickel plated copper-27% or pure nickel
Insulating system
Mica tape composite
Outer covering
High silica yarn braid with high temperature finish
Color:Natural
CHARACTERISTICS
Unique insulation system offers outstanding heat-aged flexibility for longer service life.
Excellent cutting and stripping characteristics, making it ideal for high volume manufacturing and assembly.
Resists braid high .
Suitable for applications to -60C
APPLICATIONS
Be popularly used to high temperature conditions in Electron, Home Appliance, Lamp, Appliance, etc.
We have got UL, ISO9001 Certifications.
500deg.C high temperature high temperature wire | ||||
Size | Conductor | Insulation Thickness | Braid Thickness | Diameter |
AWG | Structure | (mm) | (mm) | (mm) |
24 | 7/0.2 | ≥0.4 | ≥0.18 | 1.8±0.2 |
22 | 7/0.254 | 2.0±0.2 | ||
20 | 10/0.254 | 2.2±0.2 | ||
18 | 16/0.254 | 2.4±0.2 | ||
16 | 26/0.254 | 2.7±0.2 | ||
14 | 41/0.254 | 3.1±0.2 | ||
12 | 65/0.254 | 3.8±0.2 | ||
10 | 103/0.254 | ≥0.51 | ≥0.38 | 4.7±0.2 |
8 | 163/0.254 | 6.1±0.2 | ||
